Diodes D5V0F4U10LP - Manual (Page 3)

D5V0F4U10LP
Document number: DS35456 Rev. 3 - 2
3 of 4
www.diodes.com
July 2013
© Diodes Incorporated
D5V0F4U10LP
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
0
t, TIME (µs)
Figure 3 Pulse Waveform
20 40 60
100
50
0
Peak Value I
pp
Half Value I /2
pp
8x20 Waveform
as defined by R.E.A.
I
, PE
AK P
U
L
S
E
CURRENT
(
%
I
)
Pp
p
P
0.1
1
10
100
1000
300 500 700 900 1100
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
Figure 4 Typical Forward Characteristics
I
, I
N
ST
ANT
A
N
E
O
US F
O
R
WA
R
D
C
U
R
R
ENT (
m
A
)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
0.1
1
10
100
0 1 2 3 4 5 6
I
, L
E
AKA
G
E
C
U
R
R
E
N
T
(n
A
)
R
Figure 5 Typical Reverse Characteristics
V , REVERSE VOLTAGE (V)
R
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
0.4
0.45
0.5
0.55
0.6
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5
V , REVERSE VOLTAGE (V)
R
Figure 6 Total Capacitance vs. Reverse Voltage
C
,
T
O
T
AL
C
A
P
A
C
IT
AN
C
E (
p
F
)
T
f = 1MHz
Note 8
U-DFN2510-10
Dim Min Max Typ
A 0.545 0.605 0.575
A1 0 0.05 0.03
A3 - - 0.13
b 0.15 0.25 0.20
b1 035 0.45 0.40
D 2.450 2.575 2.500
e - - 0.50
E 0.950 1.075 1.000
L 0.325 0.425 0.375
Z - - 0.150
All Dimensions in mm
Z
b 1
R 0
. 1
2 5
R 0 . 0 7 5
D
E
e b
L
A
A 1
A 3
S e a t i n g P l a n e
