Diodes APT13003D - Manual (Page 4)

APT13003D
Datasheet Number: DS36347 Rev. 1 - 2
4 of 7
www.diodes.com
July 2013
© Diodes Incorporated
A Product Line of
Diodes Incorporated
APT13003D
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ. Max Unit Test Condition
Collector-Emitter Breakdown Voltage BV
CES
700
 
V I
C
= 100µA, V
BE
= 0V
Collector-Emitter Breakdown Voltage BV
CEO
450
 
V I
C
= 100µA
Emitter-Base Breakdown Voltage BV
EBO
9   V I
E
= 100µA
Collector Cutoff Current I
CEV
 
10 µA V
CE
= 700V, V
BE
= -1.5V
DC current transfer Static ratio (Note 7) h FE
16
5.0


30
25

I
C
= 0.5A, V
CE
= 2V
I C = 1.0A, V CE = 2V
Collector-Emitter Saturation Voltage (Note 7) V
CE(sat)




0.3
0.4
V
I
C
= 0.5A, I
B
= 0.1A
I
C
= 1A, I
B
= 0.25A
Base-Emitter Saturation Voltage (Note 7) V
BE(sat)




1.0
1.2
V
I
C
= 0.5A, I
B
= 0.1A
I
C
= 1A, I
B
= 0.25A
Output Capacitance C
ob
 18  pF V
CB
= 10V, f = 0.1MHz
Transition Frequency f
T
4   MHz I
C
= 0.1A, V
CE
= 10V
Turn-on Time with Resistive Load t
on
 
0.7
µs
I
C
= 1A,V CC = 125V, I B1 = 0.2A,
I
B2
= -0.2A
Storage Time with Resistive Load t s
  3.0
Fall Time with Resistive Load t
f
  0.35
Note: 7. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤2%.
Typical Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
