Ordering Information
(Note 5)
Device
Packaging
Shipping
DC0150ADJ-7
SOT-963
10,000/Tape & Reel
DC0150BDJ-7
SOT-963
10,000/Tape & Reel
Notes:
5. For packaging details, go to our websit
Marking Information
Package Outline Dimensions
SOT-963
Dim
Min
Max Typ
A
0.40
0.50 0.45
A1
0
0.05 -
c
0.077
0.177 0.127
D
0.95
1.05 1.00
E
0.95
1.05 1.00
E1
0.75
0.85 0.80
L
0.05
0.15 0.10
b
0.10
0.20 0.15
e
0.35 Typ
e1
0.70 Typ
All Dimensions in mm
xx= Product Type Marking Code:
T1 = DC0150ADJ
T2 = DC0150BDJ
xx
L
c
E
D
e1
e
E1
b (5 places)
A
A1
