DC0150ADJ / DC0150BDJ
Document number: DS31480 Rev. 3 - 2
2 of 6
April 2009
© Diodes Incorporated
DC0150ADJ / DC0150BDJ
NEW PROD
UC
T
Electrical Characteristics–Q1 NPN
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 4)
Collector-Base Breakdown Voltage
V(
BR)CBO
60 — — V
I
C
= 10
μA, I
E
= 0
Collector-Emitter Breakdown Voltage
V(
BR)CEO
50 — — V
I
C
= 1mA, I
B
= 0
Emitter-Base Breakdown Voltage
V(
BR)EBO
5 — — V
I
E
= 10
μA, I
C
= 0
Collector Cut-Off Current
I
CBO
— — 0.1
μA
V
CB
= 60V, I
E
= 0
Emitter Cut-Off Current
I
EBO
— — 0.1
μA
V
EB
= 5V, I
C
= 0
ON CHARACTERISTICS (Note 4)
Collector-Emitter Saturation Voltage
V
CE(SAT)
— 0.10
0.25 V
I
C
= 100mA, I
B
= 10mA
DC Current Gain DC0150ADJ
DC0150BDJ
h
FE
120 — 240
—
V
CE
= 6V, I
C
= 2mA
200 — 400
SMALL SIGNAL CHARACTERISTICS
Transition Frequency
f
T
60 — —
MHz
V
CE
= 10V, I
E
= -1mA
f = 30MHz
Output Capactiance
C
ob
— 1.3 — pF
V
CB
= 10V, I
E
= 0,
f = 1MHz
Electrical Characteristics–Q2 PNP
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 4)
Collector-Base Breakdown Voltage
V(
BR)CBO
-50 — — V
I
C
= -10
μA, I
E
= 0
Collector-Emitter Breakdown Voltage
V(
BR)CEO
-50 — — V
I
C
= -1mA, I
B
= 0
Emitter-Base Breakdown Voltage
V(
BR)EBO
-5 — — V
I
E
= -10
μA, I
C
= 0
Collector Cut-Off Current
I
CBO
— — -0.1
μA
V
CB
= -50V, I
E
= 0
Emitter Cut-Off Current
I
EBO
— — -0.1
μA
V
EB
= -5V, I
C
= 0
ON CHARACTERISTICS (Note 4)
Collector-Emitter Saturation Voltage
V
CE(SAT)
— -0.15 -0.3 V
I
C
= -100mA, I
B
= -10mA
DC Current Gain DC0150ADJ
DC0150BDJ
h
FE
120 — 240
—
V
CE
= -6V, I
C
= -2mA
200 — 400
SMALL SIGNAL CHARACTERISTICS
Transition Frequency
f
T
80 — —
MHz
V
CE
= -10V, I
E
= 1mA
f = 30MHz
Output Capactiance
C
ob
— 1.6 — pF
V
CB
= -10V, I
E
= 0,
f = 1MHz
Notes:
4. Measured under pulsed conditions. Pulse width = 300µs. Duty cycle
≤2%
0
0
P
, PO
W
E
R DIS
S
IP
A
T
IO
N (
W
)
D
T , AMBIENT TEMPERATURE ( C)
A
°
Fig. 1 Power Dissipation vs. Ambient Temperature (Note 3)
50
100
150
200
250
25
50
75
100
125
150
300
R
= 417°C/W
θJA
1
10
100
1,000
0.1
1
10
100
-V
, COLLECTOR-EMITTER VOLTAGE (V)
CE
Fig. 2 Typical Collector Current
vs. Collector-Emitter Voltage (Note 3)
-I
,
C
O
LL
E
C
T
O
R
C
U
R
R
EN
T
(mA
)
C
Pw = 100ms
Pw = 10ms
DC
