DCP69/-16/-25
Document number: DS30798 Rev. 7 - 2
4 of 5
www.diodes.com
April 2012
© Diodes Incorporated
DCP69/-16/-25
0
20
40
60
0.01 0.1 1 10 100
V , REVERSE VOLTAGE (V)
R
CAP
A
CIT
A
NCE
(
p
F
)
Fig. 7 Typical Output Capacitance Characteristics
f = 1MHz
C
obo
0
50
100
150
200
250
0 20 40 60 80 100
-I , COLLECTOR CURRENT (mA)
C
f
,
CURRENT
GA
IN-
B
A
NDW
ID
T
H P
RODUCT
(
M
Hz
)
T
Fig. 8 Typical Gain-Bandwidth Product vs. Collector Current
V = -5V
f = 100MHz
CE
Package Outline Dimensions
Suggested Pad Layout
SOT223
Dim Min Max Typ
A 1.55 1.65 1.60
A1 0.010 0.15 0.05
b1 2.90 3.10 3.00
b2 0.60 0.80 0.70
C 0.20 0.30 0.25
D 6.45 6.55 6.50
E 3.45 3.55 3.50
E1 6.90 7.10 7.00
e — — 4.60
e1 — — 2.30
L 0.85 1.05 0.95
Q 0.84 0.94 0.89
All Dimensions in mm
Dimensions Value (in mm)
X1 3.3
X2 1.2
Y1 1.6
Y2 1.6
C1 6.4
C2 2.3
A1
A
X2
C1
C2
X1
Y2
Y1
