ABSOLUTE MAXIMUM RATINGS
Supply Voltage
-0.6V to 12V
Supply Current
100mA
Input Voltage (V
POL
)
25V Continuous
Drain Current (per FET)
0 to 15mA
(set by R
CAL
)
Operating Temperature
-40 to 70°C
Storage Temperature
-50 to 85°C
Power Dissipation (T
amb
=
25°C)
QSOP20
500mW
ELECTRICAL CHARACTERISTICS. TEST CONDITIONS
(Unless otherwise stated):T
amb
=
25°C,V
CC
=5V,I
D
=10mA (R
CAL
=33k
Ω
)
SYMBOL PARAMETER
CONDITIONS
LIMITS
UNITS
MIN.
TYP.
MAX.
V
CC
Supply Voltage
5
10
V
I
CC
Supply Current
I
D1
to I
D3
=0
I
D1
=0,I
D2
to I
D3
=10mA, V
POL
=14V
I
D2
=0,I
D1
to I
D3
=10mA, V
POL
=15.5V
I
D1
to
I
D3
=0, I
LB
=10mA
I
D1
to
I
D3
=0, I
HB
=10mA
6
25
25
16
16
15
35
35
25
25
mA
mA
mA
mA
mA
V
SUB
Substrate
Voltage
(Internally generated) I
SUB
=0
I
SUB
=-200
µ
A
-3.5
-3.0
-2.5
-2.4
V
V
E
ND
E
NG
Output Noise
Drain Voltage
Gate Voltage
C
G
=4.7nF, C
D
=10nF
C
G
=4.7nF, C
D
=10nF
0.02
0.005
Vpkpk
Vpkpk
f
O
Oscillator
Frequency
200
350
800
kHz
ZNBG3210
ZNBG3211
67-2
