Package Outline Dimensions
Note: Controlling dimensions are in millimetres. Approximate dimensions are provided in inches.
The package appearance may vary as shown, for further details please contact your local Diodes sales office.
Ordering Information
(Note x)
Device Package
Reel Size
(inches)
Tape Width
(mm)
Quantity
(per reel)
ZNBG3118JA16TC QFN1633 13 8 3000
Marking Information
QFN16 3x3
Dim Min Max
A 0.55 0.65
A1 0.00 0.05
A3 0.15 Typ
b 0.18 0.28
D 2.95 3.05
D2 1.40 1.60
e 0.50 BSC
E 2.95 3.05
E2 1.40 1.60
L 0.35 0.45
Z 0.625 Typ
All Dimensions in mm
E
D
E2
e
b
Z
D2
L
A
A3
A1
Pin #1 ID
ZNBG
3118
YYWW
Pin 1
Part Name
Date Code
Year/Week
