ZLNB2012
APPLICATION CIRCUIT EXAMPLES
PROVISIONAL ISSUE A - OCTOBER 2001
6
Vcc
LNB Downfeed No.1
CF1
10nF
RP1
1.0k
LNB Downfeed No.2
CF2
10nF
RP2
1.0k
TD2
BHOR2
HOR2
ENA2
GND
TD1
HOR1
VCC
BHOR1
FIN1
ENA1
VPOL2 VPOL1
BTD2
1
FIN2
BTD1
The following circuit shows the additional components that will be used for polarisation mode and 22kHz tone
detection in typical ZLNB2012 application (ZLNB2012 Pinout for QSOP16 package designator - Q16).
TD2
HOR2
BHOR2
ENA2
GND
BTD1
TD1
HOR1
VCC
FIN1
ENA1
VPOL2 VPOL1
BTD2
BHOR1
1
FIN2
ZLNB2012 PINOUT FOR QSOP16
PACKAGE DESIGNATOR - Q16
Part Number Package Part Mark
ZLNB2012Q16 QSOP16 ZLNB2012
ORDERING INFORMATION
Part Number Package Part Mark
#ZLNB2012Q16 QSOP16 ZLNB2012
SAMPLE ORDERING INFORMATION
