ZLNB2012
PROVISIONAL ISSUE A - OCTOBER 2001
2
ABSOLUTE MAXIMUM RATINGS
Supply Voltage -0.6V to 12V
Supply Current 500mA
V POL1 and V POL2
Input Voltage 25V Continous
Operating Temperature -40 to 80°C
Storage Temperature -40 to 85°C
Power Dissipation (T
amb 25 C)
QSOP16 500mW
SYMBOL PARAMETER CONDITIONS LIMITS UNITS
Min Typ Max
V
CC
Supply Voltage 5 8 V
I
CC
Supply Current HOR1,2= BHOR1,2= TD1,2= BTD1, 2= 0mA
V
POL
1= V
POL
2= Don’t Care
F
IN
1= F
IN
2= Don’t Care
9 12 mA
V
POL1
and V
POL2
Inputs
I
POL
V
TPOL
T
SPOL
Current
Threshold Voltage
Switching Speed
V
POL1
= V
POL2
= 25V (Note 2)
T
amb
=-40°C to 80°C
100
14
200
14.25
240
14.5
100
␮A
V
␮S
HOR
OUT
1 and HOR
OUT
2 Outputs
VHOR
HIGH
VHOR
LOW
Voltage High
Voltage Low
IHOR
OUT
1,2=-100 ␮A,V
POL
1,2=14.5V
IHOR
OUT
1,2=5mA,V
POL
1,2=14V
V
CC
-1.0
0
V
CC
0.7
0.30
V
CC
0.5
V
V
BHOR
OUT
1 and BHOR
OUT
2 Outputs
VBHOR
HIGH
VBHOR
LOW
Voltage High
Voltage Low
IBHOR
OUT
1,2=-100 ␮A,V
POL
1,2=14.0V
IBHOR
OUT
1,2=5mA,V
POL
1,2=14.5V
V
CC
-1.0
0
V
CC
0.7
0.30
V
CC
0.5
V
V
Enable 1,2
Outputs
VEN
HIGH
VEN
LOW
Voltage High
Voltage Low
IEnable 1,2=-100 ␮A,V
POL
1,2=10V
IEnable 1,2=500 ␮A,V
POL
1,2=8.0V
V
CC
-1.0
0
V
CC
0.7
0.30
V
CC
0.5
V
V
Filter Amplifier
V
OUT
Bias Voltage
3
I
fin
=0 1.75 1.95 2.15 V
F
inz
Input Impedance V
FIN
=100mV p/p 150 ⍀
AG Amplifier Gain V
FIN
=100mV p/p 30 V/mA
FV
T
V Threshold
3
100 170 350 mV
p/p
ELECTRICAL CHARACTERISTICS TEST CONDITIONS (Unless otherwise stated):
T
amb = 25 ЊC,VCC =5V
Note:-
1) The parameters Filter Amplifier V OUT , I OUT , Rectifier V OUT and Comparator Threshold Voltage are all directly (linearly)
related to Vcc.
2) Applied via 1k resistors
3) These parameters are linear related to V
CC
