ZXRE060
0.6V ADJUSTABLE PRECISION SHUNT REGULATOR
ZXRE060
Document number: DS33611 Rev. 6 - 2
10 of 12
www.diodes.com
March 2011
© Diodes Incorporated
A Product Line of
Diodes Incorporated
Ordering Information
Tol. Order Code Part
Identification
Code
Reel Size Tape Width Quantity/Reel
0.5%
ZXRE060AET5TA TSOT23-5 S6A 7”, 180mm 8mm 3000
ZXRE060AH5TA SC70-5/SOT353 S6A 7”, 180mm 8mm 3000
ZXRE060AFT4-7 DFN1520H4-6 S6A 7”, 180mm 8mm 3000
1%
ZXRE060ET5TA TSOT23-5 S06 7”, 180mm 8mm 3000
ZXRE060H5TA SC70-5/SOT353 S06 7”, 180mm 8mm 3000
ZXRE060FT4-7 DFN1520H4-6 S06 7”, 180mm 8mm 3000
Notes: 4. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf
Marking Information
1. TSOT23-5, SC70-7/SOT353
2. DFN1520H4-6
Package Packing
ET5: TSOT23-5
H5: SC70-5/SOT353
FT4: DFN2015H4-6 -7: Tape & Reel
TA: Tape & Reel
XX
Tolerance Package Packing
A: ±0.5%
None: ±1%
X XXX ZXRE060
Package Packing
ET5: TSOT23-5
H5: SC70-5/SOT353
FT4: DFN2015H4-6 -7: Tape & Reel
TA: Tape & Reel
XX
Tolerance Package Packing
A: ±0.5%
None: ±1%
X XXX ZXRE060
1 2 3
5 7 4
XXX
( Top View )
XXX : Identification code
1 2 3
5 7 4
XXX
( Top View )
XXX : Identification code
Y : Year : 0~9
W : Week : A~Z : 1~26 week;
( Top View )
X : A~Z : Internal Code
Y W X
XXX
XXX : Identification code
z : represents 52 and 53
a~z : 27~52 week;
1 2 3
4 5 6
1 2 3
4 5 6
Y : Year : 0~9
W : Week : A~Z : 1~26 week;
( Top View )
X : A~Z : Internal Code
Y W X
XXX
XXX : Identification code
z : represents 52 and 53
a~z : 27~52 week;
1 2 3
4 5 6
1 2 3
4 5 6
