ZSR SERIES
Issue 9 - October 2007 14 www.zetex.com
© Zetex Semiconductors plc 2007
Obsolete Variants
SOT223 Order information
TO92 Order information
NOTES:
* TO92 was supplied in the following reel options:
loose in boxes of 4000
suffix: L
taped and wound on a reel of 1500 suffix: STOB
taped and folded in concertina form of 1500 suffix: STZ
TO92 Package suffix - C
Orderable Voltage Part
marking
Status Reel size
(inches)
Tape width
(mm)
Quantity
per reel
ZSR285GTA 2.85V ZSR285 Obsolete 7 12 1000
ZSR400GTA 4.0V ZSR400 Obsolete 7 12 1000
ZSR485GTA 4.85V ZSR485 Obsolete 7 12 1000
ZSR520GTA 5.2V ZSR520 Obsolete 7 12 1000
ZSR600GTA 6.0V ZSR600 Obsolete 7 12 1000
ZSR900GTA 9.0V ZSR900 Obsolete 7 12 1000
Part Number Voltage Part marking Status Orderable
ZSR285 2.85V ZSR285 Obsolete ZSR285C*
ZSR300 3.0V ZSR300 Obsolete ZSR300C*
ZSR330 3.3V ZSR330 Obsolete ZSR330C*
ZSR400 4.0V ZSR400 Obsolete ZSR400C*
ZSR485 4.85V ZSR485 Obsolete ZSR485C*
ZSR500 5.0V ZSR500 Obsolete ZSR500C*
ZSR520 5.2V ZSR520 Obsolete ZSR520C*
ZSR600 6.0V ZSR600 Obsolete ZSR600C*
ZSR800 8.0V ZSR800 Obsolete ZSR800C*
ZSR900 9.0V ZSR900 Obsolete ZSR900C*
ZSR1000 10.0V ZSR100 Obsolete ZSR1000C*
ZSR1200 12.0V ZSR1200 Obsolete ZSR1200C*
IN
Underside view
GND
OUT
