ZSR SERIES
3.0 to 12 volt fixed positive local voltage regulator
SOT223 ordering information
Description
The ZSR Series three terminal fixed positive
voltage regulators feature internal circuit
current limit and thermal shutdown making the
devices difficult to destroy. The devices are
available in a high power surface mount
package, ideal for applications where space
saving is important. The devices are suited to
local voltage regulation applications, where
problems could be encountered with distributed
single source regulation, as well as more
general voltage regulation applications.
The ZSR Series show performance
characteristics superior to other local voltage
regulators. The initial output voltage is
maintained to within 2.5% with a quiescent
current of typically 350
A. Output voltage
change, with input voltage and load current, is
much lower than competitive devices. The ZSR
devices are completely stable with no external
components.
Features
•
Output current up to 200mA
•
Tight initial tolerance of 2.5%
•
Low 600
A quiescent current
•
-55 to 125°C temperature range
•
No external components
•
Internal thermal shutdown
•
Internal short circuit current limit
•
High power SOT223 package
SOT223 Package suffix - G
Top view –
Connect pin 4 to pin 2 or leave pin 4
electrically isolated
Order reference
Voltage
Part
marking
Status
Reel size
(inches)
Tape width
(mm)
Quantity
per reel
ZSR300GTA
3.0V
ZSR300
Active
7
12
1000
ZSR330GTA
3.3V
ZSR330
Active
7
12
1000
ZSR500GTA
5.0V
ZSR500
Active
7
12
1000
ZSR800GTA
8.0V
ZSR800
Active
7
12
1000
ZSR1000GTA
10.0V
ZSR100
Active
7
12
1000
ZSR1200GTA
12.0V
ZSR1200
Active
7
12
1000
OUT
1
4
2
3
GND
Top view
IN
GND
