ZXBM2004
TWO PHASE VARIABLE SPEED
MOTOR CONTROL PRE-DRIVER
ZXBM2004
Document number: DS33433 Rev. 5 - 2
4 of 19
February 2012
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings
(T
A
= 25
°C, unless otherwise noted, Note 2)
Symbol
Characteristics
Values
Unit
V
CCMAX
Supply voltage
-0.6 to +20
V
I
CCMAX
IC input current
100
mA
P
DMAX
Power Dissipation (Note 4)
QSOP-16 500
mW
U-QFN3030-16 (Note 3)
1500
T
A
Operating ambient temperature
-40 to +110
o
C
T
STG
Storage Temperature Range
-55 to +150
o
C
Note:
2. Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability
may be affected by exposure to absolute maximum rating conditions for extended periods of time.
3. U-QFN3030-16 dissipation is based on a two-layer 2oz. copper 2”x 2” FR4 substrate PCB with thermal vias to the bottom layer.
Recommended Operating Conditions
(T
A
= 25
°C)
Symbol
Parameter
Conditions
Min
Max
Unit
V
CC
Supply Voltage
Operating
4.7
18.0 V
T
A
Operating Temperature Range
Operating
-40
+110
o
C
Electrical Characteristics (
T
A
= 25
°C, V
CC
= 12V
)
Symbol
Characteristics
Conditions
Min
Typ.
Max
Unit
I
CC
Supply Current
No Load (Note 4)
- 5.5
7.5
mA
VIN
Hall amplifier input voltage
Diff peak to peak
40
mV
V
CM
Hall amplifier common mode voltage
0.5
V
CC
-1.5
V
V
OFS
Hall amplifier input offset voltage
±7
mV
I
BS
Hall amplifier bias current
400
700
nA
V
OH
Ph1 and Ph2 output high voltage
I
OH
= 80mA
V
CC
-2.2
Vcc -1.8
V
V
OLA
Ph1 and Ph2 output low voltage
I
OH
=16mA (Note 5)
0.4
0.6
V
V
OLB
Ph1 and Ph2 output low voltage
I
OH
= 50uA (Note 6)
0.4
0.6
V
I
OH
Ph1 and Ph2 output source current
80
mA
I
OL
Ph1 and Ph2 output sink current
16
mA
I
PWMC
C
PWM
charge current
4.5
7.85
µA
I
PWMD
C
PWM
discharge current
38
65
µA
V
THH
C
PWM
high threshold voltage
3
V
V
THL
C
PWM
low threshold voltage
1
V
F
PWM
PWM frequency
C
PWM
= 0.1nF
24
kHz
Notes:
4. Measure with pins H+, H-, C
LCK
and C
PWM
and all other signal pins open circuit
5. Measured when opposing Phase Output is Low
6. Measured when opposing Phase Output is High
