ZXBM2004
TWO PHASE VARIABLE SPEED
MOTOR CONTROL PRE-DRIVER
ZXBM2004
Document number: DS33433 Rev. 5 - 2
13 of 19
February 2012
© Diodes Incorporated
NEW PROD
UC
T
Application Note
(cont.)
Bipolar Transistors
Part Number
Type
V
CEO
( V )
I
C
( A )
V
CE(sat)
@I
C
/I
B
( mV @ A/mA )
Package
Power switch
FZT855
NPN
150
4
65 @ 0.5/50
SOT223
FMMT624
NPN
125
1
150 @ 0.5/50
SOT23
ZX5T853G
NPN
100
6
125 @ 2/100
SOT223
ZXTN19100CZ
NPN
100
5.25
65 @ 1/100
SOT89
ZXTN25100BFH
NPN
100
3
135 @ 0.5/10
SOT23
ZXTN25100DFH
NPN
100
2.5
170 @ 0.5/10
SOT23
FCX493
NPN
100
1
300 @ 0.5/50
SOT89
FCX1053A
NPN
75
3
200 @ 1/10
SOT89
ZXTN19060CG
NPN
60
7
155 @ 1/10
SOT223
ZX5T851G
NPN
60
6
135 @ 2/50
SOT223
DXT2010P5
NPN
60
5
70 @ 1/10
PowerDI5
FCX493A
NPN
60
1
500 @ 1/50
SOT89
FCX619
NPN
50
3
260 @ 2/50
SOT89
FMMT619
NPN
50
2
220 @ 2/50
SOT23
FCX619
NPN
50
3
260 @ 2/50
SOT89
Drive buffer and level shift
FMMT493
NPN
100
1
300 @ 0.5/50
SOT23
FMMT493A
NPN
60
1
250 @ 0.5/50
SOT23
ZXTN2038F
NPN
60
1
250 @ 0.5/50
SOT23
DSS4160
NPN
60
1
140 @ 0.5/50
SOT563
