Ordering Information
Part Number
Packaging
Status
Part
Marking
Reel
Quantity
Tape Width
Reel Size
ZXLD1370EST16TC TSSOP-16EP Active
ZXLD
1370
YYWW
2500 16mm
13”
ZXLD1370QESTTC TSSOP-16EP Active
2500
16mm
13”
Where YY is last two digits of year and WW is two digit week number
Package Outline Dimensions
(All dimensions in mm.)
Suggested Pad Layout
TSSOP-16EP
Dim
Min
Max Typ
A
-
1.20 -
A1
0.025 0.100
-
A2
0.80 1.05 0.90
b
0.19 0.30 -
c
0.09 0.20 -
D
4.90 5.10 5.00
E
6.20
6.60 6.40
E1
4.30
4.50 4.40
e
0.65 BSC
L
0.45
0.75 0.60
L1
1.0 REF
L2
0.65 BSC
X
-
- 2.997
Y
-
- 2.997
θ1
0°
8° -
All Dimensions in mm
Dimensions
Value
(in mm)
C
0.650
X
0.450
X1
3.290
X2
5.000
Y
1.450
Y1
3.290
Y2
4.450
Y3
7.350
Y2
Y (16x)
Y3
C
Y1
X2
X1
X (16x)
ID MARK
PIN 1
E
E1
D
e
b
A1
A2
A
DETAIL
Seating Plane
θ1
Gauge Plane
0.25
X
Y
L
L1
