ZXSC300
ISSUE 4 - SEPTEMBER 2007
3
FMMT617
For the circuits described in the applications section, Zetex FMMT617 is the recommended pass transistor. The
following indicates outline data for the transistor, more detailed information can be found at
www.zetex.com/FMMT617
ELECTRICAL CHARACTERISTICS (at T
A
= 25°C unless otherwise stated).
PARAMETER
SYMBOL MIN.
TYP.
MAX.
UNIT
CONDITIONS
Collector-Emitter
Saturation Voltage
V
CE(sat)
8
70
150
14
100
200
mV
mV
mV
I
C
=0.1A, I
B
=10mA*
I
C
=1A, I
B
=10mA*
I
C
=3A, I
B
=40mA*
Collector-Emitter
Breakdown Voltage
V
(BR)CEO
15
18
V
I
C
=10mA*
*Measured under pulsed conditions. Pulse width=300
μs. Duty cycle ≤ 2%
ZHCS1000
For the circuits described in the applications section Zetex ZHCS1000 is the recommended Schottky diode. The
following indicates outline data for the diode, more detailed information is available at www.zetex.com
ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER
SYMBOL
MIN.
TYP.
MAX.
UNIT
CONDITIONS
Forward Voltage
V
F
400
500
mV
mV
I
F
=500mA
I
F
=1A
Reverse Current
I
R
50
100
μA
V
R
=30V
Reverse Recovery
Time
t
rr
12
ns
Switched from I
F
= 500mA
to I
R
= 500mA. Measured
at I
R
=50mA
*Measured under pulsed conditions. Pulse width=300
μs. Duty cycle ≤ 2%
