ZXLD1321
Issue 1 - January 2008
5
www.zetex.com
© Zetex Semiconductors plc 2008
Electrical characteristics (
Test conditions: VIN = 3V, T
AMB
= 25
°
C unless otherwise stated
(a)
)
DC-DC converter supply parameters
NOTES:
(a) Production testing of the device is performed at 25
°
C. Functional operation of the device and parameters specified from -40
°
C to
+125
°
C are guaranteed by design, characterisation and process control.
(b) Between 1.2V and 2.2V the device will run in the Low Voltage Startup Mode (for details refer to section "Low Voltage Operation")
DC-DC converter input parameters
Symbol
Parameter
Conditions
Min
Typ
Max
Units
V
IN
Supply voltage
Normal operation
2.0
12
V
V
IN
(Start)
Supply voltage for start-up
(b)
Start-up mode
1.2
2.4
V
V
UV-
Under-voltage detection threshold
Normal operation to start-up mode
VIN falling
1.8
V
V
UV+
Under-voltage detection threshold
Start-up mode to normal operation
VIN rising
2.2
V
Iq
Quiescent current
Measured into VIN
ADJ pin floating.
(Excluding switch
base current).
1.5
mA
I
STBY
Standby current
Measured into VIN.
ADJ pin grounded
12
20
µA
V
REF
Internal reference voltage
ADJ pin floating 480 500 520 mV TCO (REF) Internal reference temperature 50 ppm /K Symbol Parameter Conditions Min Typ Max Units V SENSE Peak switch current sense Measured on ISENSE 45 55 65 mV V SENSE (SU) Peak switch current sense Measured on ISENSE 10.5 mV I SENSE Sense input current Measured into with pin at 0V. CFB pin at 0V -15 -7 -1 µA C FB Control loop compensation 10 nF V ADJ External dc control voltage DC brightness 50 500 mV V ADJ(th) Switching threshold of ADJ Standby state to 26 28 30 mV TCO (VADJ) Temperature coefficient of +0.3 %/K R ADJ Internal resistor between VADJ<500mV 100 k Ω VADJ(clmp) Clamp voltage on ADJ pin 100µA injected into 575 mV
2.0V
coefficient.
voltage
pin CFB pin at 0V
voltage in start-up mode
pin.
Start-up mode
VIN=1.2V
ISENSE
capacitor
applied to ADJ pin to adjust
output current
control mode
pin
normal operation
VADJ(th)
VREF and ADJ
ADJ pin
