ZXMC6A09DN8
ISSUE 4 - MAY 2005
5
PARAMETER SYMBOL MIN. TYP. MAX. UNIT CONDITIONS
STATIC
Drain-Source Breakdown Voltage V
(BR)DSS
-60 V I
D
=-250 µA, V
GS
=0V
Zero Gate Voltage Drain Current I
DSS
-1.0 ␮A V
DS
=-60V, V
GS
=0V
Gate-Body Leakage I
GSS
100 nA V
GS
= Ϯ20V, V
DS
=0V
Gate-Source Threshold Voltage V
GS(th)
-1.0 V I
D
=-250 ␮A, V
DS
= V
GS
Static Drain-Source On-State Resistance
(1)
R
DS(on)
0.055
0.080 ⍀
⍀
V
GS
=-10V, I
D
=-3.5A
V
GS
=-4.5V, I
D
=-2.9A
Forward Transconductance (1)(3) g
fs
8.7 S V
DS
=-15V,I
D
=-3.5A
DYNAMIC (3)
Input Capacitance C
iss
1580 pF
V
DS
=-30 V, V
GS
=0V,
f=1MHz
Output Capacitance C
oss
160 pF
Reverse Transfer Capacitance C
rss
140 pF
SWITCHING (2) (3)
Turn-On Delay Time t
d(on)
4.6 ns
V
DD
=-30V, I
D
=-1A
R
G
6.0 Ω, V
GS
=-10V
Rise Time t
r
5.8 ns
Turn-Off Delay Time t
d(off)
55 ns
Fall Time t
f
23 ns
Gate Charge Q
g
23 nC V
DS
=-30V,V
GS
=-5V,
I
D
=-3.5A
Total Gate Charge Q
g
44 nC
V
DS
=-30V,V
GS
=-10V,
I
D
=-3.5A
Gate-Source Charge Q
gs
3.9 nC
Gate-Drain Charge Q
gd
9.8 nC
SOURCE-DRAIN DIODE
Diode Forward Voltage (1) V
SD
-0.85 -0.95 V T
J
=25°C, I
S
=-4.2A,
V
GS
=0V
Reverse Recovery Time (3) t
rr
37 ns T
J
=25°C, I
F
=-2.1A,
di/dt= 100A/ µs
Reverse Recovery Charge
(3)
Q
rr
56 nC
P-CHANNEL
ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated)
NOTES
(1) Measured under pulsed conditions. Width ≤300µs. Duty cycle ≤ 2% .
(2) Switching characteristics are independent of operating junction temperature.
(3) For design aid only, not subject to production testing.
