ZXMP10A18G
Document Number DS33598 Rev. 2 - 2
1 of 8
December 2011
© Diodes Incorporated
A Product Line of
Diodes Incorporated
ZXMP10A18G
ADVAN
CE I
N
F
O
RM
ATI
O
N
100V P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(on)
max
I
D
max
T
A
= 25
°C
(Notes 3)
-100V
150m
Ω @ V
GS
= -10V
-3.7A
190m
Ω @ V
GS
= -6V
-3.3A
Description and Applications
This MOSFET has been designed to minimize the on-state resistance
and yet maintain superior switching performance, making it ideal for
high efficiency power management applications.
• Motor
control
• DC-DC
Converters
•
Power management functions
•
Relay and solenoid driving
Features and Benefits
• Low
on-resistance
•
Fast switching speed
•
“Green” component. Lead Free Finish / RoHS compliant
(Note 1)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SOT223
•
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: Finish - Matte Tin Solderable per MIL-STD-202,
Method 208
•
Weight: 0.112 grams (approximate)
Ordering Information
(Note 1)
Product
Marking
Reel size (inches)
Tape width (mm)
Quantity per reel
ZXMP10A18GTA ZXMP10A18
7
12
1,000
Note:
1. Diodes, Inc. defines “Green” products as those which are RoHS compliant and contain no halogens or antimony compounds. All applicable RoHS
exemptions applied. Further information about Diodes Inc.’s “Green” Policy can be found on our website.
Marking Information
Equivalent Circuit
D
S
G
ZXMP = Product Type Marking Code, Line 1
10A18 = Product Type Marking Code, Line 2
Top View
SOT223
Pin Out - Top View
ZXMP
10A18
