ZXMP4A16G
S E M I C O N D U C T O R S
2
ISSUE 4 - JULY 2003
PARAMETER
SYMBOL
LIMIT
UNIT
Drain-Source Voltage
V
DSS
-40
V
Gate-Source Voltage
V
GS
Ϯ20
V
Continuous Drain Current (V
GS
= -10V; T
A
=25°C)
(b)
(V
GS
= -10V; T
A
=70°C)
(b)
(V
GS
= -10V; T
A
=25°C)
(a)
I
D
-6.4
-5.1
-4.6
A
Pulsed Drain Current
(c)
I
DM
-21
A
Continuous Source Current (Body Diode)
(b)
I
S
-5.2
A
Pulsed Source Current (Body Diode)(c)
I
SM
-21
A
Power Dissipation at T
A
=25°C
(a)
Linear Derating Factor
P
D
2.0
16
W
mW/°C
Power Dissipation at T
A
=25°C
(b)
Linear Derating Factor
P
D
3.9
31
W
mW/°C
Operating and Storage Temperature Range
T
j
:T
stg
-55 to +150
°C
ABSOLUTE MAXIMUM RATING
PARAMETER
SYMBOL
VALUE
UNIT
Junction to Ambient
(a)
R
θ
JA
62.5
°C/W
Junction to Ambient
(b)
R
θ
JA
32.2
°C/W
THERMAL RESISTANCE
NOTES
(a) For a device surface mounted on 25mm x 25mm FR4 PCB with high coverage of single sided 1oz copper,
in still air conditions
(b) For a device surface mounted on FR4 PCB measured at t
р10 secs.
(c) Repetitive rating 25mm x 25mm FR4 PCB, D=0.05 pulse width limited by maximum junction temperature.
