ZXMN6A07F
Document Number DS33547 Rev. 7 - 2
2 of 8
October 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
ZXMN6A07F
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
60 V
Gate-Source Voltage
V
GS
±20 V
Continuous Drain Current
V
GS
= 10V
T
A
= +25°C (Note 7)
T
A
= +70°C (Note 7)
T
A
= +25°C (Note 6)
I
D
1.4
1.1
1.2
A
Pulsed Drain Current (Note 8)
I
DM
6.9 A
Continuous Source Current (Body Diode) (Note 7)
I
S
1 A
Pulsed Source Current (Body Diode) (Note 8)
I
SM
6.9 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation (Note 6)
Linear Derating Factor
P
D
625
5
mW
mW/°C
Power Dissipation (Note 7)
Linear Derating Factor
P
D
806
6.4
mW
mW/°C
Thermal Resistance, Junction to Ambient
(Note 6)
R
θJA
200
°C/W
(Note 7)
155
Thermal Resistance, Junction to Ambient (Note 9)
R
θJL
194
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Notes:
6. For a device surface mounted on 25mm x 25mm FR4 PCB with high coverage of single sided 1oz copper, in still air conditions
7. For a device surface mounted on FR4 PCB measured at t ≤5 secs.
8. Repetitive rating 25mm x 25mm FR4 PCB, D=0.02 pulse width=300μs - pulse current limited by maximum junction temperate
9. Thermal resistance from junction to solder-point (at the end of the drain lead).
