ZXTP558L
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Collector-Base Voltage
V
CBO
-400 V
Collector-Emitter Voltage
V
CEO
-400 V
Emitter-Base Voltage
V
EBO
-7 V
Continuous Collector Current
I
C
-500 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation (Note 5)
P
D
1 W
Thermal Resistance, Junction to Ambient (Note 5)
R
θJA
125
°C/W
Thermal Resistance, Junction to Lead (Note 6)
R
θJL
50
°C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
ESD Ratings
(Note 7)
Characteristic Symbol
Value
Unit
JEDEC
Class
Electrostatic Discharge - Human Body Model
ESD HBM
≥ 8,000
V
3B
Electrostatic Discharge - Machine Model
ESD MM
≥ 400
V
C
Notes:
5. For the through-hole device mounted vertically, in still air conditions, with the lead length 6mm from the bottom of package to the board.
6. Thermal resistance from junction to solder-point (2mm from the bottom of package along the collector lead).
7. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
