ZXTN26070CV

Document number: DS32129 Rev. 3 - 2

4 of 7

www.diodes.com

April 2010

© Diodes Incorporated

A Product Line of

Diodes Incorporated

ZXTN26070CV








Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

OFF CHARACTERISTICS
Collector-Base Breakdown Voltage

V

(BR)CBO

150 190

V

I

C

= 100µA

Collector-Emitter Breakdown Voltage (Note 7)

V

(BR)CEO

70 80

V

I

C

= 10mA

Emitter-Base Breakdown Voltage

V

(BR)EBO

7 8.3

V

I

E

= 100µA

Collector Cutoff Current

I

CBO

, I

CES

100 nA

V

CB

= 60V , V

CES

= 60V

Emitter Cutoff Current

I

EBO

100 nA

V

EB

= 5.6V

ON CHARACTERISTICS (Note 7)

DC Current Gain

h

FE

190
200

75

320
340
110



I

C

= 10mA, V

CE

= 5V

I

C

= 100mA, V

CE

= 5V

I

C

= 2A, V

CE

= 5V

Collector-Emitter Saturation Voltage

V

CE(SAT)





22

110
147
135
265

30

150
200
165
330

V

I

C

= 0.1A, I

B

= 10mA

I

C

= 0.5A, I

B

= 10mA

I

C

= 1A, I

B

= 50mA

I

C

= 1A, I

B

= 100mA

I

C

= 2A, I

B

= 200mA

Base-Emitter Turn-On Voltage

V

BE(ON)

0.85 1.0

V I

C

= 1A, V

CE

= 2V

Base-Emitter Saturation Voltage

V

BE(SAT)

0.90 1.1

V I

C

= 1A, I

B

= 50mA

SMALL SIGNAL CHARACTERISTICS
Output Capacitance

C

obo

10

pF

V

CB

= 10V. f = 1MHz

Current Gain-Bandwidth Product

f

T

200

MHz

V

CE

= 10V, I

C

= 50mA,

f = 100MHz

SWITCHING CHARACTERISTICS
Turn-On Time

t

on

46

ns

V

CE

= 10V, I

C

= 0.5A

I

B1

= -I

B2

= 25mA

Turn-Off Time

t

off

722

ns

Notes:

7. Measured under pulsed conditions. Pulse width = 300µs. Duty cycle

≤ 2%
