ZXTC6718MC
PNP - Electrical Characteristics
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
-25 -35 - V I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 12) BV
CEO
-20 -25 - V I
C
= -10mA
Emitter-Base Breakdown Voltage BV
EBO
-7 -8.5 - V I
E
= -100µA
Collector Cutoff Current I
CBO
- - -100 nA V
CB
= -20V
Emitter Cutoff Current I
EBO
- - -100 nA V
EB
= -6V
Collector Emitter Cutoff Current I
CES
- - -100 nA V
CES
= -16V
Static Forward Current Transfer Ratio (Note 12) h
FE
300
300
150
15
475
450
230
30
-
-
-
-
-
I
C
= -10mA, V
CE
= -2V
I
C
= -100mA, V
CE
= -2V
I
C
= -2A, V
CE
= -2V
I
C
= -6A, V
CE
= -2V
Collector-Emitter Saturation Voltage (Note 12) V
CE(sat)
-
-
-
-
- -19
-170
-190
-240
-225
-30
-220
-250
-350
-300
mV
I C = -0.1A, I B = -10mA
I
C
= -1A, I
B
= -20mA
I
C
= -1.5A, I
B
= -50mA
I
C
= -2.5A, I
B
= -150mA
I
C
= -3.5A, I
B
= -350mA
Base-Emitter Turn-On Voltage (Note 12) V BE(on)
- -0.87 -0.95 V I
C = -3.5A, V CE = -2V
Base-Emitter Saturation Voltage (Note 12) V
BE(sat)
- -1.01 -1.12 V I
C
= -3.5A, I
B
= -350mA
Output Capacitance C
obo
- 21 30 pF V
CB
= -10V. f = 1MHz
Transition Frequency f T
150 180 - MHz
V
CE
= -10V, I
C
= -50mA,
f = 100MHz
Turn-on Time t
on
- 40 - ns V CC = -10V, I C = -1A
I
B1
= I
B2
= -10mA Turn-off Time t
off
- 670 - ns
Notes: 12. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
