SD101AW - SD101CW
Ordering Information
(Note 5)
Part Number Case Packaging
SD101xW-7-F SOD-123 3000/Tape and Reel
SD101xW-13-F SOD-123 10,000/Tape and Reel
Notes: 5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
xx = Product Type Marking Code
S1 or SK = SD101AW
S2 or SK = SD101BW
S3 or SK = SD101CW
YM = Date Code Marking
Y = Year (ex: T = 2006)
M = Month (ex: 9 = September)
XX
YM
Date Code Key
Year 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015
Code J K L M N P R S T U V W X Y Z A B C
Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Package Outline Dimensions
SD101AW - SD101CW
Document number: DS11012 Rev. 19 - 2
3 of 3
www.diodes.com
July 2008
© Diodes Incorporated
Suggested Pad Layout
