SD101AW - SD101CW
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 4) SD101AW
SD101BW
SD101CW
V
(BR)R
60
50
40
⎯
V
I
R
= 10
μA
I
R
= 10
μA
I
R
= 10
μA
Forward Voltage Drop
SD101AW
SD101BW
SD101CW
SD101AW
SD101BW
SD101CW
V
FM
⎯
0.41
0.40
0.39
1.00
0.95
0.90
V
I
F
= 1.0mA
I
F
= 1.0mA
I
F
= 1.0mA
I
F
= 15mA
I
F
= 15mA
I
F
= 15mA
Peak Reverse Current (Note 4)
SD101AW
SD101BW
SD101CW
I
RM
⎯
200
nA
V
R
= 50V
V
R
= 40V
V
R
= 30V
Total Capacitance
SD101AW
SD101BW
SD101CW
C
T
⎯
2.0
2.1
2.2
pF
V
R
= 0V, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
1.0
ns
I
F
= I
R
= 5.0mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
4. Short duration pulse test used to minimize self-heating effect.
SD101AW - SD101CW
Document number: DS11012 Rev. 19 - 2
2 of 3
www.diodes.com
July 2008
© Diodes Incorporated
0.01
0.1
1.0
10
0
0.5
1
I
, INS
.0
T
AN
T
AN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(mA
)
F
A
B
C
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
F
0.0001
0.1
1
10
0
20
40
60
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
R
I
, I
N
S
T
ANT
A
NE
O
U
S REV
E
RSE
CUR
R
ENT (
µ
A)
R
10
30
50
0.001
0.01
0
1
2
0
10
20
30
40
50
C
,
T
O
T
AL
C
A
P
A
C
IT
AN
C
E (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 3 Total Capacitance vs Reverse Voltage
R
T = 25 C
f = 1MHz
j
°
0
200
500
0
25
50
75
125
150
P
,
P
O
WE
R
DI
SSI
P
A
T
IO
N (
m
W
)
D
T , AMBIENT TEMPERATURE (°C)
Fig. 4 Power Derating Curve
A
100
100
300
400
See Note 1
