SBR8A60P5
Document number: DS35382 Rev. 3 - 2
3 of 4
www.diodes.com
January 2012
© Diodes Incorporated
SBR8A60P5
NEW PROD
UC
T
SBR and POWERDI are registered trademarks of Diodes Incorporated.
NEW PROD
UC
T
0 5 10 15 20 25 30 35 40
Fig. 3 Total Capacitance vs. Reverse Voltage
V , DC REVERSE VOLTAGE (V)
R
C
, T
O
T
A
L
CAP
A
C
IT
A
NCE
(
p
F
)
T
100
1,000
10,000
f = 1MHz
0
25
50
75
100
125
150
200
0 6 12 18 24 36 42 48 54 60
Fig. 4 Operating Temperature Derating
V , DC REVERSE VOLTAGE (V)
R
T
,DERA
TE
D AM
BI
ENT
T
E
M
PERA
T
URE
(
C
)
A
° 175
0
2
4
6
8
10
12
25 50 75 100 125 150
T , AMBIENT TEMPERATURE (°C)
A
Fig. 5 Forward Current Derating Curve
I,
A
V
E
R
A
G
E F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
Note 3
175
Based on Lead Temp (T )
L
Package Outline Dimensions
POWERDI ® 5
Dim Min Max
A 1.05 1.15
A2 0.33 0.43
b1 0.80 0.99
b2 1.70 1.88
D 3.90 4.05
D2 3.054 Typ
E 6.40 6.60
e 1.84 Typ
E1 5.30 5.45
E2 3.549
Typ
L 0.75 0.95
L1 0.50 0.65
W 1.10 1.41
All Dimensions in mm
E
E1
b1
A
A2
A2
D
b2
b1
e
D2
L
E2
L1
W
