SBR8A60P5
Document number: DS35382 Rev. 3 - 2
2 of 4
January 2012
© Diodes Incorporated
SBR8A60P5
NEW PROD
UC
T
SBR and POWERDI are registered trademarks of Diodes Incorporated.
NEW PROD
UC
T
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
60 V
Average Rectified Output Current @T
C
= 140ºC
I
O
8 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
160 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance Junction to Ambient (Note 3)
R
θJC
5
ºC/W
Maximum Thermal Resistance Junction to Ambient (Note 3)
R
θJA
37
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
- 0.46 -
V
I
F
= 5A, T
J
= 25ºC
- 0.55
0.62
I
F
= 8A, T
J
= 25ºC
Leakage Current (Note 4)
I
R
- 0.092
0.5
mA
V
R
= 60V, T
J
= 25ºC
- -
100
V
R
= 60V, T
J
= 125ºC
Notes:
3. Device mounted on Polymide 10cmX10cm copper PC board,
4. Short duration pulse test used to minimize self-heating effect.
0
100
200
300
400
500
600
Fig. 1 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
0.01
0.1
1
10
100
I
, INS
T
AN
T
AN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
0
10
20
30
40
50
60
Fig. 2 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
1
10
100
1,000
100,000
I
, INS
T
A
NT
A
NE
OU
S
R
EV
E
R
SE
C
U
R
R
EN
T
(
µ
A
)
R
10,000
T = 25°C
A
T = 85°C
A
T = 125°C
A
