ZHCS2000
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage V
(BR)R
40 - - V I
R
= 1mA
Forward Voltage (Note 4) V
F
- 290 325
mV
I F = 500mA
- 340 385 I
F
= 1000mA
- 380 445 I
F
= 1500mA
- 420 500 I F = 2000mA
- 485 615 I
F
= 3000mA
- 420 - I
F
= 2000mA, T
A
= 100°C
Reverse Current I
R
- 160 300 μA V
R
= 30V
Diode Capacitance C
D
- 50 - pF f = 1MHz, V
R
= 25V
Reverse Recovery Time trr - 5.5 - ns
Switched from I
F
= 500mA to
I
R
= 500mA
Measured @ I
R
= 50mA
Notes: 4. Measured under pulsed conditions. Pulse width = 300 μS. Duty cycle ≤ 2%.
