SBR140S1F
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
RM
40 V
RMS Reverse Voltage V
R(RMS)
28 V
Average Rectified Output Current I
O
1 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on Rated Load
I
FSM
30 A
Thermal Characteristics
Characteristic Symbol Value Unit
Thermal Resistance Junction to Case (Note 5)
Thermal Resistance Junction to Ambient (Note 5) R
θJC
R
θJA
24
95
°C/W
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage (Note 6) V
(BR)R
40 — — V I
R
= 200µA
Forward Voltage Drop V
F
— 0.44 0.51 V I
F
= 1A, T
J
= +25°C
Leakage Current (Note 6) I
R
— 20 100 µA V
R
= 40V, T
J
= +25°C
Notes: 5. Device mounted on FR-4 substrate, 1.0"*1.0", 2oz, single-sided, PC boards with 0.2"*0.25" copper pad.
6. Short duration pulse test used to minimize self-heating effect.
