SBR140S1F


1A SBR

®

SUPER BARRIER RECTIFIER

Product Summary

V

RRM

(V)

I

O

(A) V

F(MAX)

(V)@ +25°C

I

R(MAX)

(mA) +25°C

40 1

0.51

0.1


Description and Applications

The SBR140S1F is a single rectifier packaged in SOD123F. Offering
low VF and excellent high temperature stability this device is ideal
for use in general rectification applications as a :

 Boost

Diode

 Blocking

Diode

 Blocking

Dode








Features and Benefits

Low forward voltage (V

F

) minimizes conduction losses and

improving efficiency

Reduced high temperature reverse leakage; Increased reliability
against thermal runaway failure in high temperature operation

Qualified to AEC-Q101 Standards

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Mechanical Data

 Case:

SOD123F

Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Matte Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208

Polarity: Cathode Band

Weight: 0.0016 grams (approximate)













Ordering Information

(Note 4)

Part Number

Case

Packaging

SBR140S1F-7

SOD123F

3000/Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http”//www.diodes.com/products/packages.html

Marking Information









Date Code Key

Year 2013 2014 2015 2016 2017 2018 2019 2020

Code

A B C D E F G H

Month

Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec

Code

1 2 3 4 5 6 7 8 9 O N D



Top View

SOD123F

F4 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex.: A = 2013
M = Month (ex: 9 = September)

F4

YM
