AVSL 152.765 THE FLY - Manual (Page 14)

152.763UK User Manual
DMX parameters
Channel Parameter Value Function
CH1 Mode
000-027 Laser off
028-055 Auto mode RBP
056-083 Auto mode blue
084-111 Auto mode red
112-139 Auto mode purple
140-167 Sound activated mode RBP
168-195 Sound activated mode blue
196-223 Sound activated mode red
224-251 Sound activated mode purple
252-255 DMX mode
CH2 Pattern 000-255 32 Patterns as shown in PATTERN LIST
CH3 Colour
000-049 RBP
050-074 Blue
075-099 Red
100-124 Purple
125-149 Alternate blue/red
150-174 Alternate red/purple
175-199 Alternate blue/purple
200-224 Alternate blue/red/purple
225-255 Color rolling
CH4 Colour speed 000-255 Stop then slow to fast
CH5 Zoom
000-127 100%-5% Size
128-169 Zooming in
170-209 Zooming out
210-255 Zooming in & out
CH6 X-axis
000-127 128 different fixed position on X
128-191 Clockwise rotation
128-255 Anticlockwise rotation
CH7 Y-axis
000-127 128 different fixed position on Y
128-191 Clockwise rotation
128-255 Anticlockwise rotation
CH8 Y-axis roll
000-127 0 -359 degree fixed Y axis rolled
128-191 Clockwise rolling
192-255 Anticlockwise rolling
CH9 X-axis roll
000-127 0 -359 degree fixed X axis rolled
128-191 Clockwise rolling
192-255 Anticlockwise rolling
CH10 Z-axis
000-127 0 -359 degree fixed Z-axis rotation
128-191 Clockwise rotation
128-255 Anticlockwise rotation
