AVSL 152.765 THE FLY - Manual (Page 11)

152.763UK User Manual
Microphone sensitivity
In sound-activated mode, the sensitivity of the internal microphone can be adjusted via the
control panel. To set the sensitivity level, do the following…
 Press the FUNC button and navigate until  is displayed
 Press ENTER and 10 levels are available using the UP and DOWN buttons
o  = lowest sensitivity,  = highest sensitivity
 Press ENTER to confirm the required sensitivity level
Master/Slave mode
One or more THE FLY lasers can be operated simultaneously in slave mode from a master unit
operating in auto or sound-activated mode.
To set up a master/slave chain, connect a DMX lead from the DMX output of the master unit
and connect to the DMX input of the slave unit. Further slave units can be connected from the
first slave unit via DMX in the same manner.
To enable slave mode on the unit(s) to be controlled…
 Press the FUNC button until  is displayed.
 6 options are available using the UP and DOWN buttons
o  - Mimics the master unit exactly
o  - Mimics the master unit with a 0.2 second delay
o  - Mimics the master unit with a 0.4 second delay
o  - Mimics the master unit with a 0.6 second delay
o  - Mimics the master unit with a 0.8 second delay
o  - Mimics the master unit with a 1.0 second delay
 The slave mode is only active when a master signal is received via DMX
