2 Quality Control Certification


Date:

Customer: Order No.:

Pass

Model

( ) GPR-2500 Oxygen Transmitter
( ) GPR-2500MO Oxygen Purity Transmitter

Sensor

( ) GPR-11-32-4 Oxygen Sensor (GPR-2500)
( ) XLT-11-24-4 Oxygen Sensor (GPR-2500)
( ) GPR-11-120-OP Oxygen Purity Sensor (GPR-2500MO)
( ) Other _____________________

Serial Nos.:

Analyzer: Sensor:

Accessories:

Owner’s Manual

Configuration:

( ) A-1151-E-L2 PCB Assembly Main / Display (GPR-2500)
( ) A-1151-E-L3 PCB Assembly Main / Display (GPR-2500MO)

Software rev:

( ) Ranges GPR-2500: 0-1%, 0-5%, 0-10%, 0-25%
( ) Range GPR-2500MO: 0-100%

Power: 12-36V DC two wire loop power

NEMA 4 rated wall mount enclosure

Barometric pressure compensation

Test:

Default zero (without sensor)

Default span @ 40uA (GPR-2500) or 20uA (GPR-2500MO)

Analog signal output 4-20mA full scale

Calibrates with adequate span adjustment within 10-50% FS

Baseline drift on zero gas <

± 2% FS over 24 hour period

Noise level <

± 1.0% FS

Span adjustment within 10-50% FS

Final:

Overall inspection for physical defects

Options:

Notes:

1 of 1 analyzer due ASAP
