17
The transmitter is equipped with a safety fuse rated at 1A 250 V (Manufacturer, Littelfuse, Part Number 370-
1100). When replacing the fuse, use a compatible fuse only ( described above).
Power
Fuse
Transmitter Ground
12-24
VDC
1
A,
F
type
Note: The male and female terminals snap together. Ensure that the male terminal is fully inserted and
secured into the female terminal block.
