Air Suspension A-2724 REV 1 User Manual
Page 4
4
REV 1
12/13/2013
A-2724
A-
2724
ARNOTT REAR AIR SPRING
FOR
2002-2009
MERCEDES-BENZ E-CLASS
FOR
2005-2011
MERCEDES-BENZ CLS-CLASS
(EXC. AMG)
FIGURE 2
3.
REMOVE THE BOLTS FROM FENDER WELL. (FIGURE 2)
4.
REMOVE THE PUSH PINS FROM FENDER WELL TO EXPOSE THE SENSOR JUNCTION BLOCK. (FIGURE 3)
FIGURE 3
FIGURE 4
5.
MARK THE CONNECTIONS TO ENSURE PROPER PLACEMENT IN REASSEMBLY, REMOVE RETAINING CLIP
AND UNPLUG SENSOR LINES. (FIGURE 4)
