Air Suspension A-2724 REV 1 User Manual
Page 11
11
REV 1
12/13/2013
A-2724
A-
2724
ARNOTT REAR AIR SPRING
FOR
2002-2009
MERCEDES-BENZ E-CLASS
FOR
2005-2011
MERCEDES-BENZ CLS-CLASS
(EXC. AMG)
FIGURE 19
FIGURE 20
21.
REMOVE THE CAPS FROM THE CALIPER MOUNTING BOLTS, LOOSEN AND REMOVE BOLTS. (FIGURE 20)
20.
UNPLUG THE BRAKE PAD WEAR SENSORS. (FIGURE 19)
22.
REMOVE CALIPERS, AND SUSPEND WITH CABLE TIES. (FIGURE 21)
FIGURE 21
