The ASUS P2L97-S Motherboard

II. FEATURES

II. FEA

TURES

(Motherboard Parts)

USB Port 1 (Top)
USB Port 2 (Bottom)

COM 2
(Bottom)

Programmable
2MB Flash ROM

3 PCI Slots

Accelerated
Graphics Port

1 ISA Slot

1 ISA/PCI
Shared Slot

PS/2 Mouse (Top)
PS/2 K’board (Bottom)

Parallel (Top)
Serial (Bottom)

3 DIMM
Sockets

Intel 440LX AGPset

Hardware
Monitor

Multi-I/O

Floppy Disk Drive
Connector

SEC CPU Slot

COM 1
(Bottom)

Narrow/Wide SCSI Connectors

Adaptec’s 7880
Ultra-Fast/Wide

SCSI Chipset

Intel PIIX4 PCIset
