Cache Vault Accessory Kit
3. Put the cable through the hole on
the bracket.
4. Place the bracket into the server
system and secure it with screws.
5. Connect the cable from the Cache
Vault Power Module to the Cache
Vault Flash Module that is installed
on the PIKE 2208 card.
6. Install the PIKE 2208 card to the
riser card bracket.
7. Install the bracket to the system
according to the instructions in the
server system's user manual.
For more details on how to
uninstall the riser card bracket,
refer to the user manual that
came with your server system.
2. Take out the riser card bracket from
the right side of the server system.
Align the screw holes on the holder
assembly to the screws holes on
the bracket, then secure the holder
assembly with a screw.
For more details on how to
uninstall the riser card bracket,
refer to the user manual that
came with your server system.
