Cache Vault Accessory Kit
Package contents
If any of the above items is damaged or missing, contact your retailer.
LSI ® MegaRAID ® Cache Vault Accessory Kit
Cache Vault Flash Module
(CVFM02)
Screws (1): 3 screws for
Cache Vault Flash Module
Cache Vault Power Module
(CVPM02)
24” cable extender LSI ® steel CVPM clip
Screws (2): For LSI ® steel
CVPM clip (3 screws, 3 screw
caps*)
ASUS Accessory Kit
Steel bracket (1 x Full-
height, 1 x Half-height)
Screws (3): 2 screws for the
steel bracket
Screws (4): 3 screws** for ASUS
steel CVPM clip holder
* Use these screws (2) and screw
caps when installing LSI ® steel
CVPM clip on ASUS steel CVPM
clip holder. Use the screw caps
depending on the situation.
(Supported servers: RS720-X7/
RS8, RS720-E7/RS12, RS720-
E7/RS12-E)
** Use these screws (4) when
installing LSI ® steel CVPM
clip directly on ASUS servers.
(Supported servers: RS920-E7/
RS8, RS926Q-E7/RS8)
ASUS steel CVPM clip
holder
42” cable extender
2
