Chapter 5: BIOS setup
5-24
5.4.11 Intel
®
Server Platform Services
This item displays information on the Intel
®
Server Platform Services configured in the
system.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Intel Sever Platform Services Configuration
ME BIOS Interface Ver :
1.0
SPS Version
3.0.4.118
ME FW Status Value :
0xf0345
ME FW State :
SPS ME FW Active
ME FW Operation State :
M0 without UMA
ME FW Error Code :
No Error
ME NM FW Status Value :
0x80000001
BIOS Booting Mode :
Power Optimized Mode
Cores Disabled :
0
ME FW SKU Information :
Node Manager
End-of-POST Status :
EOP disabled in POST
5.4.12 Onboard LAN Configuration
This area allows you to configure the onboard LAN.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
INTEL I210 LAN Disable/
Enable
INTEL I210 LAN1 Enable
[Enabled]
INTEL I210 LAN1 OpROM
[PXE]
INTEL I210 LAN2 Enable
[Enabled]
INTEL I210 LAN2 OpROM
[PXE]
INTEL I210 LAN1 - LAN2 Enable [Enabled]
Allows you to enable or disable the INTEL I210 LAN function in the system. Configuration
Options: [Enabled] [Disabled]
INTEL I210 LAN1 - LAN2 OpROM
Allows you to launch the Intel I210 LAN OpROM. Configuration options: [Disabled] [PXE]
[iSCSI]
Onboard LAN Configuration
INTEL I210 LAN1 MAC:
00:E0:18:10:18:E8
INTEL I210 LAN2 MAC:
00:E0:18:10:18:E9
Advanced
