Chapter 3: Rackmount installation 3-2
3.1 Rackmount rail kit items
The rackmount rail kit contains two pairs of rails (one pair for each side of the server system),
six (6) pieces of inner rail screws, and two (2) pieces of rack screws.
Inner rail screws Rack screws
Outer rails
Inner rails
3.2 Attaching the rails to the rack
To attach the rack rails:
1.
Attach the inner rail to the correspoding side of the chassis and secure with three inner
rail screws. Make sure the rail is oriented as shown.
