ASUS SABERTOOTH Z87 3-21
Chapter 3
CPU Cache Voltage Offset
Allows you to set the CPU cache voltage offset. By default, this item takes the standard
value of the installed CPU. You can use the <+> or <-> keys to adjust the value. The
values range from 0.001V to 0.999V with a 0.001V interval.
CPU Graphics Voltage [Auto]
Allows you to configure the voltage amount for the integrated graphics processing unit
(iGPU). Increase the voltage when setting a high iGPU frequency value.
Configuration options: [Auto] [Manual Mode] [Offset Mode] [Adaptive Mode]
The following item appears only when you set the CPU Graphics Voltage to [Manual].
CPU Graphics Voltage Override [Auto]
Allows you to set the CPU Graphics Voltage override. By default, this item takes the
standard value of the installed CPU. You can use the <+> or <-> keys to adjust the
value. The values range from 0.001V to 1.920V with a 0.001V interval.
The following items appear only when you set the CPU Graphics Voltage to [Offset Mode].
Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Graphics Voltage Offset
By default, this item takes the standard value of the installed CPU. You can
use the <+> or <-> keys to adjust the value. The values range from 0.001V
to 0.999V with a 0.001V interval.
The following item appears only when you set the CPU Graphics Voltage to [Adaptive
Mode].
Additional Turbo Mode CPU Graphics Voltage [Auto]
This item allows you to increase the voltage for Turbo Mode CPU Graphics.
By default, this item takes the standard value of the installed CPU. You can
use the <+> or <-> keys to adjust the value. The values range from 0.001V
to 1.920V with a 0.001V interval.
Total Adaptive Mode CPU Graphics Voltage [Auto]
This item sums up the voltages of the CPU Graphics Voltage offset and
Additional Turbo Mode CPU Graphics Voltage options.
CPU System Agent Voltage Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
