3-36 Chapter 3: BIOS setup
Chapter 3
ASM1061 Storage Controller (ES6_E12) [Enabled]
Allows you to enable or disable the ASM1061 Storage Controller.
Configuration options: [Disabled] [Enabled]
Hot-plug [Enabled]
Allows you to enable or disable the hot plug support.
Configuration options: [Disabled] [Enabled]
ASM1061 Storage Controller (SATA6G_E12) [Enabled]
Allows you to enable or disable the ASM1061 Storage Controller.
Configuration options: [Disabled] [Enabled]
Hot-plug [Disabled]
Allows you to enable or disable the hot plug support.
Configuration options: [Disabled] [Enabled]
PCI Express X16_3 slot (black) bandwidth [Auto]
[x4 mode] PCIe X16_3 runs at x4 mode for a high performance support.
[x1 mode] PCIe x16_3 runs at x1 mode with all slots enabled.
[Auto] PCIe x16_3 runs at x1 mode for system resource optimization.
Intel LAN Controller [Enabled]
[Enabled] Enables the Intel ® LAN controller.
[Disabled] Disables the Intel ® LAN controller.
Intel PXE OPROM [Disabled]
This item appears only when you set the Intel LAN Controller item to [Enabled] and allows
you to enable or disable the PXE OptionRom of the Intel ® LAN controller.
Configuration options: [Enabled] [Disabled]
