ASUS SABERTOOTH Z87

1-9

Chapter 1

Layout contents

Connectors/Jumpers/Slots

Page

1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)

1-32

2. CPU, optional, chassis, and assistant fan connectors (4-pin CPU_FAN,

4-pin CPU_OPT, 4-pin CHA_FAN1-4, 3-pin ASST_FAN1-2 )

1-30

3. LGA1150 CPU socket

1-10

4. DDR3 DIMM slots

1-11

5. MemOK! button

1-22

6. USB 3.0 connector (20-1 pin USB3_34)

1-27

7. Intel

Z87 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6 [brown])

1-26

8. ASMedia

Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_E12 [beige])

1-27

9. DirectKey connector (2-pin DRCT)

1-34

10. System panel connector (20-8 pin PANEL)

1-33

11. DirectKey button

1-23

12. Thermal sensor connectors (T_SENSOR1, T_SENSOR2, T_SENSOR3)

1-31

13. USB 2.0 connectors (10-1 pin USB1112, USB1314)

1-29

14. TPM connector (20-1 pin TPM)

1-34

15. Standby Power LED

1-25

16. Clear RTC RAM (3-pin CLRTC)

1-24

17. Digital audio connector (4-1 pin SPDIF_OUT)

1-28

18. Front panel audio connector (10-1 pin AAFP)

1-31
