ASUS P9X79 3-33
Chapter 3
3.5.6 Onboard Devices Configuraton
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
Enabled/Disabled Azalia HD Audio
Back Advanced\ Onboard Devices Configuration >
UEFI BIOS Utility - Advanced Mode
Azalia HD Audio Enabled
Front Panel Type HD
SPDIF Out Type SPDIF
Intel LAN Controller Enabled
Intel LAN PXE OPROM Disabled
VIA 1394 Controller Enabled
Asmedia USB 3.0 Controller Enabled
ASM1061 Storage Controller AHCI Mode
ASM1061 Storage OPROM Enabled
> Serial Port Configuration
Azalia HD Audio [Enabled]
[Disabled] Disables the controller.
[Enabled] Enables the High Definition Audio Controller.
The following two items appear only when you set the HD Audio Controller item to
[Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD]
Sets the front panel audio connector (AAFP) mode to high definition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
Intel LAN Controller [Enabled]
[Disabled] Disables the controller.
[Enabled] Enables the Intel LAN controller.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F6: ASUS Ratio Boost
F10: Save ESC: Exit
F12: Print Screen
