ASUS M5A97 3-21
Chapter 3
Power On By PME Device [Disabled]
[Disabled] Disables the PME to wake up from S5 by PCI/PCIE devices.
[Enabled] Allows you to turn on the system through a PCI/PCIE LAN or modem card.
This feature requires an ATX power supply that provides at least 1A on the
+5VSB lead.
Power On By Ring [Disabled]
[Disabled] Disables to power up the computer when the external modem receives a
call while the computer is in Soft-off mode.
[Enabled] The computer could be powered up when the external modem receives a
call while the computer is in Soft-off mode.
The computer cannot receive or transmit data until the computer and applications are fully
running. Thus, connection cannot be made on the first try. Turning an external modem
off and then back on while the computer is off causes an initialization string that turns the
system power on.
Power On By RTC [Disabled]
[Disabled] Disables RTC to generate a wake event.
[Enabled] When set to [Enabled], the items RTC Alarm Date (Days) and System
Time will become user-configurable with set values.
3.6 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2011 American Megatrends, Inc.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
UEFI BIOS Utility - Advanced Mode
CPU Temperature +45ºC / +113ºF
MB Temperature +33ºC / +91ºF
VCORE Voltage +1.380V
3.3V Voltage +3.216V
5V Voltage +5.057V
12V Voltage +11.685V
VDDA2.5V Voltage +2.520V
CPU Fan Speed 4166 RPM
Chassis Fan 1 Speed N/A
Chassis Fan 2 Speed N/A
Power Fan Speed N/A
CPU Q-Fan Control Enabled
CPU Fan Profile Standard
Cpu Fan Speed Low Limit 600 RPM
Chassis Q-Fan Control Disabled
