2-32 Chapter 2: Hardware information
Chapter 2
2.3.9 Rear panel connection
Rear panel connectors
1. PS/2 Mouse port (green) 5. Audio** I/O ports
2. Optical S/PDIF Out port 6. USB 3.0 ports 1 and 2 (blue)
3. USB 2.0 ports 1 ~ 6 7. PS/2 Keyboard port (purple)
4. LAN* (RJ-45) port
• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under
Windows ® OS environment and after the USB 3.0 driver installation.
• USB 3.0 devices can only be used as data storage only.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.
* and **: Refer to the tables on the next page for LAN port LED and audio port definitions.
