ASUS M5A97 2-3
Chapter 2
Connectors/Jumpers/Slots Page
1. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN1/2, 3-pin
PWR_FAN)
2-18
2. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-19
3. AM3+ CPU Socket 2-4
4. DDR3 DIMM slots 2-5
5. DRAM LED (DRAM_LED) 2-15
6. MemOK! switch 2-14
7. AMD ® SB950 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1~6) 2-16
8. Standby power LED (SB_PWR) 2-15
9. System panel connector (20-8 pin PANEL) 2-20
10. Clear RTC RAM (3-pin CLRTC) 2-13
11. USB connectors (10-1 pin USB78, USB910, USB1112) 2-17
12. Serial port connector (10-1 pin COM1) 2-16
13. Front panel audio connector (10-1 pin AAFP) 2-17
14. Digital audio connector (4-1 pin SPDIF_OUT) 2-18
