C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p 2 - 1 6 2 - 1 6 2 - 1 6 2 - 1 6 2 - 1 6
2.4 Hard disk drives
To install a hard disk drive:
1. Open the front bezel to access the
hot-swap drive trays.
2. Release a drive tray by pushing the
spring lock to the right, then
pulling the tray lever outward. The
drive tray ejects slightly after you
pull out the lever.
3. Firmly hold the tray lever and pull
the drive tray out of the bay.
4. An empty drive tray includes a
metal bracket for support. Use a
Phillips (cross) screwdriver to
remove the bracket if you wish to
install a hard disk in the drive tray.
Metal bracket
